长光栅光刻车间气流组织数值模拟研究▲

基金项目:

贵州省科技计划项目《施肥机械智能控制模块与电机技术研究》黔科合支撑[2019]2024号。

Numerical Simulation of Air Distribution in Long Grating Lithography Workshop

1.College of Mechanical Engineering,Guizhou Institute of Technology, Guiyang Guizhou 550003;
2.College of Mechanical Engineering,Guizhou Minzu University, Guiyang Guizhou 550025;
3.College of Mechanical Engineering,Guizhou University, Guiyang Guizhou 550025

摘要: 长光栅的光刻制造工艺是一个复杂的精密制造过程，良好的环境条件有利于提高产品质量，本文通过CFD方法模拟分析某规格长光栅光刻车间内由空调通风所形成的空气速度场及温度场，确定满足制造工艺要求的空调参数，同时研究送风温度及送风速度对车间气流组织的影响，实现有效减少试验成本及试验时间，为实际生产提供理论依据的目的。
- 光刻 /
- CFD /
- 速度场 /
- 温度场
Abstract: The lithography process of long grating is a complex and precise manufacturing process, and good environmental conditions are conducive to improving product quality. In this paper, the air velocity field and temperature field formed by air conditioning and ventilation in a long grating lithography workshop are simulated and analyzed by CFD method, and the air conditioning parameters that meet the requirements of manufacturing process are determined.At the same time, the effects of air supply temperature and air supply speed on the airflow group of workshop are studied The effect of weaving can effectively reduce the cost and time of experiment and provide theoretical basis for actual production.
- lithography /
- CFD /
- velocity field /
- temperature field

[1]	汤天瑾,曹向群,林斌.计量光栅制造综述[J].光学仪器,2004,26(4):62-67.
[2]	白杉.光刻机曝光技术演进[J].集成电路,2003(12):3-6.
[3]	董会君.温度对复制光栅衍射波前的影响[J].仪器仪表与分析监测,2000(2):31-34.
[4]	薛殿华.空气调节[M].北京:清华大学出版社,1998.
[5]	陶文锉.计算流体力学与传热学[M].北京:中国建筑工业出版社,1991.[6] 赵琴,王靖.Fluent在暖通空调领域中的应用[J].制冷与空调,2003(1):15-18.
[7]	谭洪卫.计算流体动力学在建筑环境工程上的应用[J].暖通空调,1994(4):31-36.
[8]	赵彬,李先庭,彦启森.用 CFD方法改进室内非等温送风气流组织设计[J].应用基础与工程科学学报,2002,12(4):376-386.
