1 000 t 凹体运梁车液压顶升系统设计▲

基金项目:

河北省省级科技计划资助（S&T Program of Hebei）项目（20311901D）

Design of Hydraulic Iacking System for 1000 ton Concave Girder Transport Truck

1.Qinhuangdao Tianye Tonglian Heavy Industry Technology Co., Ltd., Qinhuangdao Hebei 066004;
2.Hebei Heavy Equipment Engineering Technology Research Center, Qinhuangdao Hebei 066004

摘要: 1 000 t 运梁车的顶升系统对于预制箱梁从运梁车上起升性能起着至关重要的作用。针对1 000 t 运梁车的顶升系统，通过详细计算，得出顶升力。考虑1 000 t 运梁车的额定起升速度，对液压系统进行设计，使其满足最大负载时起升的需要，保证1 000 t 运梁车在额定负载时以额定速度正常顶升和下降；同时，使得顶升油缸起升下降稳定，不超速，并在实际运用时取得了良好效果。
- 1 000 t 凹体运梁车 /
- 液压顶升 /
- 平衡阀
Abstract: The jacking system of 1 000 t girder carrier plays an important role in lifting performance of prefabricated box girder from girder carrier. Aiming at the jacking system of 1 000 t beam truck, the jacking force is obtained through detailed calculation. Considering the rated lifting speed of 1 000 t beam truck, the hydraulic system is designed to meet the needs of lifting when the maximum load, so as to ensure the normal lifting and lowering of 1 000 t beam truck at the rated speed when the rated load; At the same time, it makes the jacking cylinder rise and fall stably, not overspeed, and has achieved good effect in practical application.
- 1 000 t concave girder carrier /
- hydraulic jacking /
- balancing valve
