水平轴风力机叶片力学性能数值模拟研究

Numerical Simulation Research on Mechanical Performance of Horizontal Axis Wind Turbine Blade

School of Mechanical and Electrical Engineering, Wuhan Institute of Technology, Wuhan Hubei 430205

摘要: 本文选取 2 kW 小型水平轴风力发电机为研究对象，首先根据其实际运行工况确定风机叶片的各项参数，通过三维建模软件建立风力机叶片的实体模型，然后使用 CAE 软件对叶片进行额定工况下的力学仿真分析。研究其在额定风速下叶片表面的应力分布和位移情况，并校核叶片强度，结果表明叶片符合安全使用要求。
- 风力发电机叶片 /
- 三维实体建模 /
- 力学仿真分析
Abstract: This paper selected a 2KW small horizontal axis wind turbine as the research object. First, the parameters of the wind turbine blade were determined according to its actual operating conditions. The solid model of the wind turbine blade was established through the 3D modeling software, and then the CAE software was used to carry out the mechanical simulation analysis of the blade under the rated working condition. The stress distribution and displacement of the blade surface under rated wind speed were studied, and the blade strength was checked. The results show that the blade meets the requirements for safe use.
- wind turbine blade /
- 3D solid modeling /
- mechanical simulation analysis

[1]	杨贺.水平轴风力机风轮气动性能研究[D].呼和浩特:内蒙古工业大学,2014.
[2]	辛东旺.风力发电机叶片三维建模及分析[D].西安:西安理工大学,2018.
[3]	李国宁,杨福增,杜白石,等.基于MATLAB与Pro/E的风力机风轮设计及造型[J].机械设计,2009,26(6):3-7.
[4]	张建平,张智伟,纪海鹏,等.碳纤维与玻璃钢风力机叶片动力特性的对比分析[J].上海电力学院学报,2019,35(6):531-534 +538.
[5]	王昊,范海哲,李帅斌.风力发电机叶片建模及有限元分析[J].上海电力学院学报,2016,32(3):257-260.
