欧式卷扬起重机杠杆式防跳槽装置的研发与应用

Development and Application of Lever Type Anti Jump Device for European Winch Crane

1.Ningbo Aotu Heavy Industry Co., Ltd., Ningbo Zhejiang 315000;
2.Ningbo Institute of Special Equipment Inspection, Ningbo Zhejiang 315000;
3.Zhoushan Special Equipment Testing and Research Institute, Zhoushan Zhejiang 316000

摘要: 针对公司 50 t 以下轻型欧式双梁卷扬式起重机起升机构钢丝绳容易发生跳槽的问题，研发制造了一种杠杆式防跳槽装置。装置能够辅助卷筒绳槽控制钢丝绳有顺序的排列缠绕在绳槽上避免跳槽，同时也使起重机具有了钢丝绳跳槽检测功能，避免因钢丝绳跳槽而发生事故，给生产带来安全隐患。
- 杠杆式 /
- 防跳槽 /
- 钢丝绳 /
- 检测 /
- 安全防护
Abstract: In view of the problem that the steel wire rope of the hoisting mechanism of the light European double beam winch crane under 50 t is easy to jump, a lever type anti jump device is developed and manufactured. The device can assist the drum rope groove to control the wire rope to be arranged in order and wound on the rope groove to avoid groove skipping. At the same time, it also enables the crane to have the function of rope groove skipping detection, so as to avoid accidents caused by rope groove skipping and bring potential safety hazards to production.
- lever type /
- anti job hopping /
- wire rope /
- detection /
- safety protection

[1]	张质文,王金诺,程文明,等.起重机设计手册(第二版)[M].北京:中国铁道出版社,2013.
[2]	钟伟旭,高海生,黄国健.门式起重机钢丝绳断绳事故分析[J].特种设备安全技术,2014(5):35-37.
[3]	彭海吉,席庆键,杜海波.钢丝绳防跳槽装置的研制及应用[J].科教导刊-电子版(上旬),2015(5):184.
[4]	董旭晨.牵引式卸船机副小车钢丝绳防跳槽装置的改进[J].港口装卸,2000(2):20.
