斗轮机液压驱动装置设计

Design of Hydraulic Drive Device of Bucket Wheel Machine

摘要: 斗轮堆取料机被广泛应用于港口、冶金、电力等领域，斗轮是斗轮堆取料机的关键组成部件。相较于传统滑阀控制、泵压控制，直接驱动式液压控制系统更高效、更节能。基于此，本文针对斗轮机液压驱动装置设计进行探讨，使用直插式阀块简化液压系统结构，提升了斗轮堆取料机运行效能。
- 斗轮堆取料机 /
- 液压驱动 /
- 驱动装置 /
- 直插式阀块
Abstract: Bucket wheel stacker and reclaimer is widely used in ports, metallurgy, electric power and other fi elds. Bucket wheel is the key component of bucket wheel stacker and reclaimer. Compared with traditional slide valve control and pump pressure control, the direct drive hydraulic control system is more effi cient and energy-saving. Based on this, this article discusses the design of the hydraulic drive device of the bucket wheel machine, and uses the in-line valve block to simplify the structure of the hydraulic system and improve the operating effi ciency of the bucket wheel stacker and reclaimer.
- bucket wheel stacker and reclaimer /
- hydraulic drive /
- drive device /
- in-line valve block

[1]	周立红.斗轮机液压系统技术改良的相关探究[J].工业C,2016 (6):26.
[2]	白旭.斗轮机液压系统技术改造[J].宁夏电力,2019(4):67-70.
[3]	陈亮.斗轮机主机俯仰直驱式液压系统静动特性及控制的研究[D].哈尔滨:哈尔滨工业大学,2011.
[4]	秦世桐.斗轮机主机俯仰直驱式液压系统静动特性及控制的研究[J].中国科技投资,2017(9):4-5.
[5]	贾延逊,黄有义,徐万鑫,等.插装阀在门式斗轮堆取料机起升机构液压系统的应用[J].起重运输机械,2015(3):66-69.
