Research on Improving the Dust Removal Efficiency of Cyclone Dust Collector for Fine Sand
-
摘要: 以 TX-18 铁路道床吸污装置中的除尘系统的旋风子作为模型，选用 Ansys 中 CFD 模块模拟了旋风除尘器在吸污过程中对粒径在 5 ～ 200 μm 范围内的沙尘的除尘效率。通过轴向速度云图、径向速度云图，研究了排气管插入深度对除尘效率的影响。利用粒子追踪对沙尘颗粒在旋风除尘器进行分析，探讨了不同粒径的沙尘的运动轨迹。结果表明，当排气管道插入深度与与吸入口高度之比为 0.8 时，具有更好的除尘效率，其能够满足对粒径为大于 40 μm 的沙尘在进行气固分离。Abstract: Taking the cyclone of the dust removal system in the TX-18 railway track bed sewage suction device as a model, the CFD module of Ansys is selected to simulate the dust removal of the dust in the range of 5~200μm in the cyclone dust collector during the dirt suction process efficient. Through the axial velocity cloud diagram and the radial velocity cloud diagram, the influence of the insertion depth of the exhaust pipe on the dust removal efficiency is studied. Particle tracing is used to analyze the dust particles in the cyclone dust collector, and the movement trajectories of sand dust with different particle sizes are discussed. The results show that when the ratio of the insertion depth of the exhaust pipe to the height of the suction port is 0.8, the dust removal efficiency is better, which can satisfy the gas-solid separation of dust with a particle size of more than 40μm.
-
Key words:
- cyclone /
- two-phase flow /
- fluid mechanics /
- CFD
-
[1] 金正.铁路大型养路机械除尘系统设计分析[J].工程技术研究, 2019,4(24):116-117. [2] Dziubak T . Experimental Studies of Dust Suction Irregularity from Multi-Cyclone Dust Collector of Two-Stage Air Filter[J]. Energies,2021,14. [3] Xie B, Li S, Jin H, et al. Analysis of the performance of a novel dust collector combining cyclone separator and cartridge filter[J].Powder technology,2018(339):695-701. [4] 岳世松.旋风除尘器内部流场的数值模拟研究[J].选煤技术, 2018(6):66-69. [5] 陈宏基,姜大志.旋风除尘器的性能及改进方案[J].化工环保,2005,25(5):409-411. [6] 王海刚,刘石.不同湍流模型在旋风分离器三维数值模拟中的应用和比较[J].热能动力工程,2003(4):337-342. [7] Long Huang, Deng S,Chen Z,et al. Numerical analysis of a novel gas-liquid pre-separation cyclone[J].Separation and Purification Technology,2018:470-479. [8] 朱挺辉,陈全民,陈金松,等.基于ANSYSCFX旋涡泵的数值模拟[J].机电技术,2013(5):55-57. [9] 李强.旋风除尘器优化设计及分离特性研究[D].长沙:中南大学,2008. -
